功能點Feature and functions
●氣動控制,操作簡單,勞動強度。
●雙手按鈕操作,安可靠。
●美國NOMEX材質溫布與溫棉,耐用、美觀、透氣性、吸水性、彈性好,熨燙質量。
●夾板模具成型,焊接工裝,表面圓弧度、直線度誤差小,熨燙。機架基本一次成型,焊接處少,不易變形,運動平穩。
●阻尼減震性好,運動平穩。安裝在機架外側,易于安裝、維護。
●運動、夾緊分別由兩個氣缸完成,運動平穩,夾緊力易于控制,熨燙質量。
●氣動元件美國制造,質量穩定,使用壽命長。
●Pneumatic control simple operation low labor intensity.
●Hands button operation safe and reliable.
●The NOMEX material at high temperature and high temperature of cotton cloth durable beautiful air permeability water absorption good elasticity ensure the ironing quality.
●Plywood die molding welding fixture that surface of the circular arc straightness error is small the ironing quality good. The basic forming a weld is little not easy to deformation stable movement.
●Damping is good ensure the smooth motion. Installed on the outer side of the frame easy installation and maintenance.
●Movement clamping were completed by two cylinder the movement is smooth the clamping force is easy to control ensure the ironing quality.
●Pneumatic components manufacturing stable quality long service life.
●氣動控制,操作簡單,勞動強度。
●雙手按鈕操作,安可靠。
●美國NOMEX材質溫布與溫棉,耐用、美觀、透氣性、吸水性、彈性好,熨燙質量。
●夾板模具成型,焊接工裝,表面圓弧度、直線度誤差小,熨燙。機架基本一次成型,焊接處少,不易變形,運動平穩。
●阻尼減震性好,運動平穩。安裝在機架外側,易于安裝、維護。
●運動、夾緊分別由兩個氣缸完成,運動平穩,夾緊力易于控制,熨燙質量。
●氣動元件美國制造,質量穩定,使用壽命長。
●Pneumatic control simple operation low labor intensity.
●Hands button operation safe and reliable.
●The NOMEX material at high temperature and high temperature of cotton cloth durable beautiful air permeability water absorption good elasticity ensure the ironing quality.
●Plywood die molding welding fixture that surface of the circular arc straightness error is small the ironing quality good. The basic forming a weld is little not easy to deformation stable movement.
●Damping is good ensure the smooth motion. Installed on the outer side of the fr
●Movement clamping were completed by two cylinder the movement is smooth the clamping force is easy to control ensure the ironing quality.
●Pneumatic components manufacturing stable quality long service life.
技術參數Technical parameters
| 參數內容 | parameters | 單位/unit | QZ2-19 |
| 蒸汽輸入、輸出口徑 | the steam input and output aperture | inch | 肩背 shoulder |
| 蒸汽壓力 | steam pressure | Mpa | DN15 |
| 蒸汽耗量 | steam consumption | Kg/h | 0.4~0.5 |
| 抽濕口徑 | wet pump diameter | inch | 15 |
| 壓縮空氣口徑 | compressed air diameters | inch | 32 |
| 空氣耗量 | air consumption | mpa | 3/8” |
| 整機凈重 | machine net weight | kg | 0.55 |
| 包裝凈重 | packing gross weight | kg | 280 |
| 外形尺寸(長×寬×) | dimension(L×W×H) | mm | 326 |
| 包裝尺寸(長×寬×) | package size(L×W×H) | mm | 940*1010*1220 |
