機器地基尺寸列表 Machine groundwork size list
技術參數：
|
機型 Models |
A(基地) A（Groundwork） |
B(地基) B（Groundwork） |
| K415 | 1500 | 760 |
| K420 | 1500 | 760 |
| K425 | 1500 | 760 |
| K428 | 1500 | 760 |
| K435 | 1500 | 760 |
|
型號/參數 Model/parameter |
K415 | K420 | K425 | K428 | K435 |
|
額定洗滌量（kg） Maximum capacity |
6 | 8 | 10 | 12 | 8 |
|
滾筒容量（Lt） Drum volume |
120 | 150 | 180 | 220 | 300 |
|
洗滌轉度（r/min） Washing speed |
34 | 34 | 34 | 34 | 34 |
|
甩干轉度（r/min） Drying speed |
600 | 600 | 600 | 600 | 600 |
| 液箱 liquid box | |||||
|
液箱1（Lt） Liquid box one |
136 | 112 | 112 | 129 | 112 |
|
液箱2（Lt） Liquid box two |
136 | 127 | 127 | 147 | 127 |
|
過濾器 Filter |
單組紙芯過濾器 Single paper core filter |
||||
|
電源要求 Power demand |
380V/3PH/50HZ | ||||
|
安裝功率（kw） Installing power |
4 | 4 | 4.5 | 4.5 | 6 |
|
蒸汽耗量（kg/h） Max steam consumption |
5-8 | 5-8 | 5-8 | 5-8 | 5-8 |
|
耗水量（kg/h） Max water consumption |
250 | 250 | 250 | 250 | 250 |
| 機器尺寸Appearance | |||||
| 寬w（mm） | 1460 | 1690 | 1690 | 1690 | 1690 |
| 深D（mm） | 1150 | 1150 | 1150 | 1250 | 1150 |
| H（mm） | 2040 | 2040 | 2040 | 2040 | 2040 |
| 機器重量Weight（kg） | 700 | 750 | 800 | 850 | 850 |
-
方便、安
電腦操作系統，實現控制洗滌、烘干、洗液還原、衣物柔軟及纖維復原整個干洗程序。手動控制系統能為一些殊需要和靈活處理提供了方便。
人性化的人機對話界面使得洗滌流程直觀明了。電腦自動檢測系統能及時指示洗衣機的運行故障，使運行安。 的安互鎖和過載保護系統裝置 ，有效的保障了機器運行的穩定性和安性。
Precise Convenient ,Safe
The computer operating system，accurately control the dry cleaning process of washing ,drying ,lotion reducing , clothing softening and fibers recovery ,Manual control system can provise convenience for some special need and flexible settlement .
Humanistic Man-machine dialogue allows washing processes intuitive . The computer system can automatically detect the operation of washing machines and overload protection device effectively protect the stability and safety of the machine .
節能 效
1使用容劑為碳氫溶劑D-40, DF-2000 ,Green eather
2不銹鋼設計，承重主軸及結構設計，確保機器長久的使用壽命。
3 兩溶劑箱設計，方便各種洗滌需求。
4.600轉/分（而不是900轉/分）的甩干速度，節省了烘干時間的能源的消耗，同時避免過的甩干速度對衣物產生損害。
5 的單組串聯式復合式過濾系列設計，配備功率溶劑泵，能夠處理敏感的衣物。
6.采用的真空防爆烘干系統，確保安可靠，縮短烘干時間。
7.采用多點溫控壓力自動保護裝置技術 ，配備性能制冷回收系統，確保溶劑的回收系統。確保溶劑的回收率95℅以上。
8.電器控制元器件，確保機器長期無故障運行。
9.簡體門及其其他清理門都裝有安自鎖裝置。
10.殊設計的溶劑箱結構，防止水分進入干洗系統。
Energy saving Efficent
1 Use of high solvent D-40,DF-2000 ，Green eather.
2 Stainless steel structure ,main bearing and structure design ensure that the machines have a long life of use
3 Tow solvent boxes are designed to facilitate a variety of washing needs
4 Drying rate ,600r/min (rather than 900r/min), saveas drying time and energy consumption while avoiding excessive drying rate for clothing which cause harm ,
5Unique single tandem consumption filter series design ,equipped with high-power solvent pump ,is capable of handing the most sensitive clothing
6 Unique vacuum explosion-proof drying system ensures safe and reliable ,shortening drying time.
7 Multi -point temperature and automatic pressure protection device technology ,equipped with high-performance cooling recovery system ,ensure solvent recovery up to 95℅ or more
8 World famous brand electrical components provide stability of the washing process without failure
9 Simplified door and other clean-up door are equipped with safety lock device
10 Special designed solvent box structure prevents water entering dry-cleaning system.
